Set span and setpoint activity properties – MTS Multipurpose Elite User Manual
Page 426
Segment Generator Callouts
Description
No.
Segment Queue
1
Segment Generator
2
Span
3
Setpoint
4
Command Signal
5
Engineering Units
eu
For More Information
Concept
Set Span and Setpoint Activity Overview
(p. 424)
Task
Setting Initial (One Time) Span and Setpoint Values
(p. 428)
Setting Continuous Span and Setpoint Values
(p. 429)
Maintaining Command to Prevent Movement
(p. 429)
Set Span and Setpoint Activity Properties
426 | MTS TestSuite
Test Activities
