Chart titles and legend – MTS Multipurpose Elite User Manual
Page 498
Description
Item
Select the thickness of the lines from 1 to 10 points.
Line Thickness
Select the line style as solid, dotted, or dashed.
Line Type
Select the type of symbol to mark the location of data points. If you do not
want to mark the data points with symbols, choose the blank selection in the
list.
Symbol Type
Select the size of the data point symbols. To automatically size the symbols,
select the multiple size image, which is the first item in the drop-down list.
Symbol Size
Chart Titles and Legend
Titles and Legends Button
Click the Titles and Legends button to open the Chart Titles and Legend window where you can configure
the details of your display and legend, such as color, font size, location in the window, and border details.
Chart Titles and Legend Window
498 | MTS TestSuite
Test-Run Displays
