Page 604: Panels properties
Layout Category
Use the tools in the Layout category to organize multiple test-run displays. You can create multiple tabs
with transitions and place panels within the tabs to delineate.
Panels
About Panels
Use panels to group and organize your displays. Double-click Panels in the Layout group of the Toolbox
panel to open two panels in the Designer tab. You can then drag and drop displays onto a panel. Configure
panel details in the Properties panel.
Panels Properties
Panels Properties Panel
Orientation
Choose Vertical or Horizontal from the drop-down menu to indicate how the panels should be positioned
on the monitor.
Panel Resizing
Panel Resizing Descriptions
Description
Item
As you resize a panel, both panels are resized
proportionally.
Both Proportionally
Select to resize only the right or bottom panel
Right or Bottom Panel
Select to resize only the left or top panel.
Left or Top Panel
604 | MTS TestSuite
Test-Run Displays
