MTS Screw-Style-5 kN User Manual
Grip-manual screw-style, 5 kn, Mts fundamental
![background image](/manuals/567952/1/background.png)
Specifications
Model
FDSC503B .01 .02
Height
132.5 mm (5.217 in)
Width
52 mm (2.047 in)
Depth
168.8 mm (6.646 in)
Weight Per Grip
2.630 kg (5.798 lb)
Maximum Load
5 kN (1100 lbf)
Jaw Code (Optional)
.01 .02
Jaw Size (w×h) (mm)
35x35
35x35
(in)
1.378x1.378 1.378x1.378
Jaw Face
Serrated
Flat
Specimen
Plastic
Textile
Jaw Opening Maximum
16 mm (0.630 in)
Interface
D
Temperature Range (℃)
0 ℃ to +50 ℃ (+32 ℉ to +122 ℉)
Saline Tolerant
No
Immersion Proof
No
Copyright information
© 2010 MTS Systems Corporation. All rights reserved.
Trademark information
MTS is a registered trademark and MTS Fundamental is
a trademark of MTS Systems Corporation within the
United States. These trademarks may be protected in
other countries.
Contact information MTS Systems Corporation
http://www.mts.com/en/Global/index.asp
ISO 9001 Certified QMS
Grip-Manual Screw-Style, 5 kN
http://support.mts.com
MTS Fundamental
™
