X-Axis and Y-Axis Properties
Description Item
Select a display unit for the selected trace signal. The list only shows the set of
units that are compatible with the dimension of the signal that is assigned to the
selected trace. Display Unit
Blank is the default value.
Set the display range of the Y axis to the maximum or minimum values. Maximum or
Minimum
Click the corresponding button to use this feature.
To have the software calculate the maximum or minimum value(s) of the Y signal
and then set the maximum or minimum display range to the value(s), click to
clear the check boxes.
To manually set the maximum or minimum display range for the Y axis, select
the check boxes and then specify the maximum or minimum values.
Set the display range of the Y axis to the amplitude or mean values. Amplitude
is a plus or minus display range. Mean is an offset, and the amplitude is relative
to the mean. Mean or
Amplitude
Click the corresponding button to use this feature.
Click to clear the check box(es) to have the application set the amplitude or
mean display range to the amplitude or mean value(s) of the X signal.
Click the check box(es) and then specify the amplitude or mean values to
manually set the amplitude or mean display range for the X axis.
The Expand Only feature was developed for auto-scaling such that when the
range expanded during auto-scaling, this option prevented the range from
contracting when the command stopped. Expand Only
Click the check box to allow a range to automatically expand if the data exceeds
the maximum and minimum ranges. The chart does not rescale to a smaller
range.
Specifying the Maximum and Minimum for an axis avoids auto-scaling, however,
also checking Expand Only implies that you want to auto-scale if the data is
outside the specified range.
Toggle between linear scale and log scale for the axis. Select the check box for
logarithmic scale. Leave the box blank for linear scale. Log Scale
X-Axis and Y-Axis Advanced Properties
Description Item
Set the base for displaying values in a logarithmic format. Click the up-arrow or
down-arrow to raise or lower the base. Log Base
