Page 411
Description
Item
You can assign the stable cycle value to any variable
that has been defined to have a dimension of count.
Stable Cycle
State Change Detection
State Change Detection Activity Overview
State Change Detection Activity Icon
The State Change Detection activity checks for a specific program state. The activity typically occurs in
parallel with other activities to limit them or provide a path if an activity fails.
For example, a parallel path contains a State Change Detection activity that monitors for a stop condition.
If the test stops, the UserStop variable is set to True.
Note:
This activity is typically only used in cyclic fatigue tests. Therefore, this activity is only available if
you have purchased and installed at least one of the following licenses: Template.HCF, Template.LCF,
Template.LCF-ElevatedTemp, Template.Trapezoidal-ElevatedTemp, Template.TMF,
Template.Transitional, Template.Transitional-ElevatedTemp.
MTS TestSuite | 411
Test Activities
