Page 172
Boolean Variable Properties
Note:
To specify that a Boolean variable hold a multiple-value array, select Array of Boolean as the Type.
Boolean variables are especially useful for showing or hiding interactive test-run displays. For an example,
see
Example: Check Box-Enabled Input Variable Test-Run Display
(p. 584).
Calculated Variables Overview
Most variable types allow you to define calculations that determine the value of the variable. The calculation
can include operations, functions, and references to other variables. The result of the calculation must
generate the same type of data that is stored in the variable.
Important:
When using calculated variables in a non-data acquisition test activity, you must add a Calculated
Variables activity to the test procedure to force the application to perform the calculation.
Calculated Variable Properties
172 | MTS TestSuite
Working with Variables
