M(T) Specimen Overview
The M(T) specimen is the middle tension specimen. It is the symmetrical, center-crack specimen used for
Fatigue Crack Growth (FCG) testing.
M(T) Specimen
M(T) Speciment Description
Definition
Item
Crack length
a
Specimen
B
Specimen length
W
Half gage length
y
For More Information
Concept
(p. 300)
(p. 302)
(p. 303)
MTS TestSuite | 301
Working with Specimens
