Description Item
For more information about block data processing, see Block Data
Processing (p. 151).
Specify the count variable that is going to be the
index or boundary identifier that defines the block. Counter
Specify the name of the block. The identifier is used
by the Block function. For example, if the identifier is
“JICStep”, it could be used as Block(“JICStep”,...) Identifier
Specify the name of the block that is shown in
variable chart views that shows boundaries of data,
such as the history view or hysteresis view. Display Name
Opens the Block Decimation Filter Selection window
in which you can specify the frequency of
downsampling. Select Blocks
For More Information
Concept
DAQ Activity Overview (p. 371)
Task
Acquiring Data While Holding (p. 375)
Collecting a Last Data Point (p. 375)
Time History Input
Time History Input Activity Overview
Time History Input Activity Icon
The Time History Input activity acquires and digitizes multiple channels of analog test response data in
the RPC III file format.
