MTS Multipurpose Elite User Manual
Page 306
Rectangular SE(B) Specimen
Rectangular SE(B)Specimen Description
Description
Item
Crack length
a
Original crack length
ao
Specimen thickness
B
Notch height
h
Specimen span
S
Specimen width
W
For More Information
Task
Reference
(p. 301)
306 | MTS TestSuite
Working with Specimens
