MTS Multipurpose Elite User Manual
Page 394
Description
Item
Click the green plus sign to open the Select Statistics
window and move the desired statistics on which to
Statistics List
gather data from the Available window to the
Selected window.
Save data to variables?
Click to open the Map Variables window.
Configure button
Log Results
•
None
•
Informational
•
Warning
•
Error
Calculation Method
•
Statistical Percentage
•
Full-Scale Percentage
•
Statistical Limits from Table
•
Range Percentage from Table
Lower Limit (-)
Upper Limit (+)
Tripped Counter
Limits Settings Table button
Advanced button
394 | MTS TestSuite
Test Activities
