a chart with a line without symbols. A line with a single value will show up as a point, as in the following
figure. This differs from Traces, where a single value will show nothing.
Indexed Values limit type
When you select Indexed Values, the values at the selected Index Variables are plotted on the chart.
Percentage Least-Squares Fit limit type
When you select Percentage Least-Squares Fit, a line will be drawn through two points that are identified
by their index.
MTS TestSuite | 571
Test-Run Displays
