Custom waveform + daq activity properties – MTS Multipurpose Elite User Manual
Page 323
Important:
This composite activity includes hard-coded settings that simplify the setup of data acquisition for
cyclic testing.
Custom Waveform + DAQ Activity Properties
Custom Waveform + DAQ Properties
Description
Item
Specify the number of times to perform the waveform defined. Click the toggle button
to specify a numeric value and unit of measure or variable.
Number of
Cycles
Select a compensator to improve the tracking and accuracy of the control loop for the
selected channel. For more information about compensators, see
(p. 133).
Compensator
Click to open the Advanced Command Properties window.
Advanced
Select an Interrupt behavior:
MTS TestSuite | 323
Test Activities
