Description Name Button
When Expand Only is enabled, the range will automatically expand or
contract if the data exceeds the maximum and minimum ranges. The
chart does not rescale to a smaller range.
Toggle
Expand
Only
When Panning is enabled, you can click and drag to move the focus of
the scope. You can only pan to the minimum and maximum ranges
available for the scope.
Toggle
Panning
When Zooming is enabled, you can click and drag to specify an area of
the scope to zoom in to. Toggle
Zooming
If zooming is enabled, resets the zoom level of the scope to the default
full scale. Reset
Zoom
Opens the Configure Chart window to further configure the functionality
and appearance of the scope. Configure
Chart
For More Information
Concept
About Scopes (p. 486)
Task
Change Monitor Display Properties During a Test Run
During a test run, you can make the following changes to the current test run when you right-click the
monitor display object:
Runtime Monitor Right-click Menu Options
Description Item
When active, the Wait for Operator Action activity adds an
Operator Buttons window to the top of the Monitor tab as the test Operator buttons
runs. When the active button is clicked, it ends the current parallel
path, to force the test to the next test activity.
Note:
The Operator Buttons window does not appear when you
preview the Monitor tab layout.
Copy the image of the display component to the clipboard. Copy Image to
Clipboard
Copy the chart data to the clipboard. Copy Values to
the Clipboard
