Max/Min DAQ Activity Properties
Description Item
Selects signals from which this process acquires
data. Use the left and right arrows to move desired
signals from the Available list to the Selected list. Signal List
Select the appropriate reference signal option. Reference Signal
Monitors the Reference signal for the maximum
values when selected. Maximum Values
Monitors the Reference signal for the minimum
values when selected. Minimum Values
No—The signal data is not put into variables. Save data to
variables?
Yes, automatically map variables—The signals
being acquired are automatically mapped to variables
using the mapping type of "Minimum" and
"Maximum," and appends "Minimum" and "Maximum"
to the signal names to form the variable names.
In addition, calculations dependent on these mapped
variables are automatically added to the Additional
Calculations list.
Yes, manually map variables—The test designer
must manually map the signals and additional
MTS TestSuite | 387
Test Activities
