Point Pick Properties
Point Pick Window
Point Pick Properties
Description
Item
Click the check box to show a circle around an individual data point and the
value of the point when selected by the mouse cursor. Deselect the check
box to suppress the data display.
Show Highlight
Circle
Show the values of two points, the difference between their values, and the
slope of a line drawn through the two points.
Show Delta and
Slope Labels
Specify the number of rows used to arrange the labels, delta, and slope. Click
the up-arrow or down-arrow to increase or decrease the number of rows. The
value range is 1 - 6.
Number of Rows
Chart Titles and Legend
Titles and Legends Button
Click the Titles and Legends button to open the Chart Titles and Legend window where you can configure
the details of your display and legend, such as color, font size, location in the window, and border details.
526 | MTS TestSuite
Test-Run Displays
