Line and Symbol Display Properties
Description Item
Adjust the opacity to better see through traces when they overlap. If you set
the opacity to a lower value, it makes the trace more transparent. Opacity
Select this check box to draw lines between data points. Clear the Draw Line
check box and click OK to only show data points if a Symbol Type is selected;
otherwise, the trace is not drawn. Draw Line
Select the thickness of the lines from 1 to 10 points. Line Thickness
Select the line style as solid, dotted, or dashed. Line Type
Select the type of symbol to mark the location of data points. If you do not
want to mark the data points with symbols, choose the blank selection in the
list. Symbol Type
Select the size of the data point symbols. To automatically size the symbols,
select the multiple size image, which is the first item in the drop-down list. Symbol Size
Limit or Curve Fit Lines Properties
To add a Limit or Curve Fit Line, click the Add a Limit or Curve Fit Line icon in the property panel title bar.
Limit or Curve Fit Lines Properties
Description Item
Click the drop-down menu, and select the color of the associated line. Color
For details about each limit types, see Limit Types (p. 519). Limit Type
• Horizontal
• Vertical
• Slope Intercept, m∙x + b
• General XY (Single Value or Array)
• Dropped Least-Squares Fit Line
• Indexed Values
• Horizontal at Index
• Vertical at Index
Select a single value variable or an array variable for which you want data plotted
on the Y axis of the chart. Y Variable
Select a single value variable or an array variable for which you want data plotted
on the X axis of the chart. X Variable
