Block or cycle decimation filter settings – MTS Multipurpose Elite User Manual
Page 152
Block Data Processing Diagram
For More Information
Task
Reference
Block or Cycle Decimation Filter Settings
(p. 152)
Block or Cycle Decimation Filter Settings
Important:
These settings do not affect data saved to variables.
To configure a block or cycle decimation filter:
1. In the Properties panel for the DAQ activity, clink the Advanced button. The Advanced Data Acquisition
window opens.
2. Click the Select Blocks button (or Select Cycles) to display the Block (or Cycle) Decimation Filter
Selection window. This window allows you to define which blocks/cycles are saved to disk.
3. Complete the properties as appropriate.
152 | MTS TestSuite
Data Acquisition (DAQ)
