X-axis and y-axis properties – MTS Multipurpose Elite User Manual
Page 574
Description
Item
Select the thickness of the lines from 1 to 10 points.
Line Thickness
Select the line style as solid, dotted, or dashed.
Line Type
Select the type of symbol to mark the location of data points. If you do not
want to mark the data points with symbols, choose the blank selection in the
list.
Symbol Type
Select the size of the data point symbols. To automatically size the symbols,
select the multiple size image, which is the first item in the drop-down list.
Symbol Size
X-Axis and Y-Axis Properties
X-Axis and Y-Axis Properties
Description
Item
Select a display unit for the selected trace signal. The list only shows the set of
units that are compatible with the dimension of the signal that is assigned to the
selected trace.
Display Unit
Blank is the default value.
574 | MTS TestSuite
Test-Run Displays
