Publication 1784-UM003A-EN-P – June 2003

Naming & Configuring Your Motion Axis 91

Data Type

In the Data Type field you can either enter the type of tag you want to create
directly or click on the ellipsis button to go to the Select Data Type dialog.
From this dialog you can select the appropriate axis data type:
AXIS_CONSUMED, AXIS_SERVO, AXIS_SERVO_DRIVE, or AXIS
VIRTUAL.

Make entries in the following fields.

Editing Motion Axis
Properties

Once you have named your axis in the New Tag window, you must then
configure it. You can make your configuring options in the Axis Properties
screen. These have a series of Tabs that access a specific dialog for configuring
the axis. Make the appropriate entries for each of the fields. An asterisk
appears on the Tab to indicate changes have been made but not implemented.
Press the Apply button at the bottom of each dialog to implement your
selections.

Field

Entry

Name

Type a name for the servo axis.
The name can:
have a maximum of 40 characters
contain letters, numbers and underscores (_).

Description

Type a description for your motion axis.
This field is optional.

Data type

AXIS_CONSUMED
AXIS_SERVO
AXIS_SERVO_DRIVE,
AXIS_VIRTUAL

Scope

Select the scope of the axis variable.

To use the axis

Select

Within the entire program

Controller

TIP

When you configure your axis, some fields may be
unavailable (greyed-out) because of choices you made in
the New Tag window.
