Publication 1784-UM003A-EN-P – June 2003

Motion Object Attributes 313

All of the fault bit attributes defined below can be handled by the
ControlLogix processor as a Major Fault by configuring the associated Group
Object’s “General Fault Type Mechanism” attribute accordingly. Otherwise
any specific fault handling must be done as part of the user program.

Control Sync Fault

The Control Sync Fault bit attribute is set when the Logix controller detects
that several position update messages in a row from the motion module have
been missed due to a failure of the synchronous communications connection.
This condition results in the automatic shutdown of the associated servo
module. The Logix controller is designed to “ride-through” a maximum of
four missed position updates without issuing a fault or adversely affecting
motion in progress. Missing more than four position updates in a row
constitutes a problematic condition that warrants shutdown of the servo
module. The Synchronous Connection Fault bit is cleared when the
connection is reestablished.

Module Sync Fault

The Module Sync Fault bit attribute is set when the motion module detects
that several position update messages in a row from the ControlLogix
processor module have been missed due to a failure of the synchronous
communications connection. This condition results in the automatic shutdown
of the servo module. The servo module is designed to “ride-through” a
maximum of four missed position updates without issuing a fault or adversely
affecting motion in progress. Missing more than four position updates in a row
constitutes a problematic condition that warrants shutdown of the servo
module. The Synchronous Connection Fault bit is cleared when the
connection is reestablished.

GSV/SSV Access

Attribute Name

Data Type

Values

GSV

Servo Module Fault
Bits

DINT

Direct Access
Entire DINT - ServoModuleFault
0: Control Sync Fault
-ControlSyncFault
1: Module Sync Fault
-ModuleSyncFault
2: Timer Event Fault
-TimerEventFault
3:Module Hardware Fault
-ModuleHardwareFault
4-31: Reserved
