42 SoftLogix Controller
Load Image
The condition under which the image stored in nonvolatile memory is loaded
back to controller memory. Available conditions include:
• On Corrupt Memory – this will cause a load whenever there is no
project in the controller and you turn on or cycle power on the chassis.
If you are using a battery the controller, selecting this option performs a
load only if the battery has failed to maintain the project during a loss of
power.
• On Power Up – this will cause a load whenever you turn on or cycle
power on the chassis. If you are using a battery on the controller,
selecting this option performs a load even if the battery has maintained
the project during loss of power.
• User Initiated – choose this option if you want to load only through
RSLogix 5000 software.
Regardless of the currently-selected load option, you can always manually
initiate a load as well.
Load Mode
The mode the controller enters upon loading from nonvolatile memory.
Choose from:
• Program (Remote Only)
• Run (Remote Only)
The Load Mode only applies if the Load Image selection is On Corrupt
Memory or On Power Up. If the Load Image is User Initiated, the Load Mode
is disabled.
Image Note
Descriptive information that you entered at the time the image was stored in
nonvolatile memory. You may enter up to 128 text characters.
TIP
The Load Mode only applies if the controller keyswitch is
in the remote position when loading. If the controller
keyswitch is in Run or Program the controller will be
returned to that mode once the load is complete. The
controller keyswitch always has priority over the Load
Mode.
