Rockwell Automation 1784-PM16SE SoftLogix Motion Card Setup and Configuration Manual User Manual
Page 218
Publication 1784-UM003A-EN-P – June 2003
210 Configuring an Ultra 3000 Drive
10. There is no Bus regulator for the Ultra3000. Press Next to continue.
Figure 9.8 Module Properties - Module Information
11. When you complete the last page, click the Finish> button. A new drive
module displays beneath the selected 1784-PM16SE motion module.
Figure 9.9 Controller Organizer - New Drive
