Motion Object Attributes 367
Drive Warning Bit Attributes All of the warning bit attributes defined below are not supported in the initial
release of this object.
Overload Warning
When the load limit of the motor is exceeded, the Overload Warning bit is set.
If the condition persists, an Overload Fault will occur. This warning bit gives
the control program an opportunity to reduce motor loading to avoid a future
shutdown situation.
Drive Overtemperature Warning
When the over-temperature limit of the drive is exceeded, the Drive
Overtemperature Warning bit is set. If the condition persists, a Drive
Overtemperature Fault will occur. This warning bit gives the control program
an opportunity to reduce motor loading, or increasing drive cooling, to avoid a
future shutdown situation.
Motor Overtemperature Warning
When the over-temperature limit of the motor is exceeded, the Motor
Overtemperature Warning bit is set. If the condition persists, an Motor
Overtemperature Fault will occur. This warning bit gives the control program
an opportunity to reduce motor loading, or increasing motor cooling, to avoid
a future shutdown situation.
Cooling Error Warning
When the ambient temperature limit inside the drive enclosure is exceeded, the
Cooling Error Warning bit is set. If the condition persists, a Cooling Error
Fault will occur. This warning bit gives the control program an opportunity to
increasing drive cooling, to avoid a future shutdown situation.
GSV/SSV Access Attribute Name Data Type Values
GSV Drive Warning Bits DINT Direct Access
Entire DINT - DriveWarnings
0: Drive Overload Warning
-DriveOverloadWarning
1: Drive Overtemperature Warning
-DriveOvertempWarning
2: Motor Overtemperature Warning
-MotorOvertempWarning
3: Cooling Error Warning
-CoolingErrorWarning
4-31: Reserved
