Publication 1784-UM003A-EN-P – June 2003
228 Configuring a Kinetix 6000 Drive
Status
Displays the status the controller has about the module:
ATTENTION
!
Changing the Electronic Keying selection may cause the
connection to the module to be broken and may result in a
loss of data.
Be extremely cautious when using this option; if used
incorrectly, this option can lead to personal injury or death,
property damage or economic loss.
This status: Indicates:
Standby A transient state that occurs when shutting down.
Faulted The controller is unable to communicate with the module.
When the status is Faulted, the Connection tab displays
the fault.
Validating A transient state that occurs before connecting to the
module.
Connecting A state that occurs while the connection(s) are being
established to the module.
Running The module is communicating and everything is working
as expected.
Shutting Down The connections are closing.
Inhibited The connection to the module is inhibited.
Waiting The connection to this module has not yet been made due
to one of the following:
• its parent has not yet made a connection to it
• its parent is inhibited§
• its parent is faulted
Offline You are not online.
