Publication 1784-UM003A-EN-P – June 2003

Naming & Configuring Your Motion Axis 111

Cycles

The number of cycles of the auxiliary feedback device. This helps the Drive
Compute Conversion constant used to convert drive units to feedback counts.
Depending on the feedback type selected, this value may either be read-only or
editable.

Per

The units used to measure the cycles.

Interpolation Factor

This field displays a fixed constant value for the selected feedback type. This
value is used to compute the resolution of the feedback device.

Feedback Ratio

Represents the quantitative relationship between the auxiliary feedback device
and the motor.

Click on the Conversion Tab to access the Axis Properties Conversion dialog.

Figure 6.17 Axis Properties - AXIS_SERVO Conversion Tab
