Configuring an Ultra 3000 Drive 215
On this tab, you can:
• Select a requested packet interval.
• Choose to inhibit the module.
• Configure the controller so loss of the connection to this module causes
a major fault.
• View module faults.
Requested Packet Interval
This field is disabled for all motion modules (e.g., 1784-PM02AE,
1784-PM16SE, and all 1394-, Ultra3000, Kinetix 6000, and 8720 modules).
Inhibit Module
Check/Uncheck this box to inhibit/uninhibit your connection to the module.
Inhibiting the module causes the connection to the module to be broken.
Note: Inhibiting/uninhibiting connections applies mainly to direct
connections, and not to the CNB module.
Note: A FLEX I/O module using rack communication cannot be
inhibited; the Inhibit checkbox on the Connection tab is disabled in this
case.
TIP
The data on this tab comes directly from the controller.
This tab displays information about the condition of the
connection between the module and the controller.
ATTENTION
!
Inhibiting the module causes the connection to the module
to be broken and may result in loss of data.
