Configuring an Ultra 3000 Drive 221
Configured
Displays a yes or no value indicating whether the module has been configured
by an owner controller connected to it. Once a module has been configured, it
stays configured until the module is reset or power is cycled, even if the owner
drops connection to the module. This information applies to I/O modules
only and does not apply to adapters, scanners, bridges, or other
communications modules.
Owned
Displays a yes or no value indicating whether an owner controller is currently
connected to the module. This information applies to I/O modules only and
does not apply to adapters, scanners, bridges, or other communications
modules.
Module Identity
This field does not take into account the Electronic Keying or Minor Revision
selections for the module that were specified on the General Tab.
Note: The Generic modules, such as the 1756-MODULE, always show
a Mismatch because the configured Generic Key does not match any
target device.
Displays: If the physical module:
Match agrees with what is specified on the General Tab order for the
Match condition to exist, all of the following must agree:
• Vendor
• Module Type (the combination of Product Type and Product
Code for a particular Vendor)
• Major Revision
Mismatch does not agree with what is specified on the General Tab
