background image

Publication 1784-UM003A-EN-P – June 2003

352 Motion Object Attributes

Acceleration Command

Acceleration Command is the current acceleration reference to the output
summing junction, in the configured axis Position Units per Second

2

, for the

specified axis. The Acceleration Command value, hence, represents the output
of the inner velocity control loop. Acceleration Command is not to be
confused with Command Velocity, which represents the rate of change of
Command Position input to the position servo loop.

Acceleration Feedback

Acceleration Feedback is the actual velocity of the axis as estimated by the
servo module, in the configured axis Position Units per Second

2

. The

Estimated Acceleration is calculated by taking the difference in the Estimated
Velocity over the servo update interval. Acceleration Feedback is a signed
value—the sign (+ or -) depends on which direction the axis is currently
moving.

Marker Distance

Marker Distance is the distance between the axis position at which a home
switch input was detected and the axis position at which the marker event was
detected. This value is useful in aligning a home limit switch relative to a
feedback marker pulse to provide repeatable homing operation.

Torque Command

This is the command value when operating in torque mode.

Torque Feedback

This is the torque feedback value when operating in torque mode.

GSV/SSV Access

Attribute Name

Data Type

Values

GSV Acceleration

Command

REAL

Position Units / Sec

2

GSV/SSV Access

Attribute Name

Data Type

Values

GSV Acceleration

Feedback

REAL

Position Units / Sec

2

GSV/SSV Access

Attribute Name

Data Type

Values

GSV

Marker Distance

REAL

Position Units

GSV/SSV Access

Attribute Name

Data Type

Values

GSV

Torque Command

REAL

%Rated

GSV/SSV Access

Attribute Name

Data Type

Values

GSV

Torque Feedback

REAL

%Rated
