Wiring diagrams, 1784-pm02ae termination panel – Rockwell Automation 1784-PM16SE SoftLogix Motion Card Setup and Configuration Manual User Manual
Page 431
Publication 1784-UM003A-EN-P – June 2003
Wiring Diagrams 423
Using a 1784-PM02AE Module With a
Velocity Servo Drive
Figure B.2 Velocity Servo Drive
Wiring Diagrams
1784-PM02AE Termination Panel
The termination panel is used in conjunction with the 1784-PM02AE card to
facilitate the wiring of drives and encoders for use with the card. Because the
card is installed inside the PC computer cabinet it would be difficult to access
