60 Adding and Configuring Your 1784-PM02AE Motion Module
Module Identity
This field does not take into account the Electronic Keying or Minor Revision
selections for the module that were specified on the General Tab.
Refresh
Click on this button to refresh the tab with new data from the module.
Reset Module
Click on this button to return a module to its power-up state by emulating the
cycling of power.
Resetting a module causes all connections to or through the module to be
closed, and this may result in loss of control.
A controller cannot be reset.
Assigning Additional
Motion Modules You can assign additional modules by repeating the preceding sections. You
can assign up to 16 1784-PM02AE modules to each Logix5000 controller.
Each module uses a maximum of two axes.
Displays: If the module in the physical slot:
Match agrees with what is specified on the General Tab. In order for the Match
condition to exist, all of the following must agree:
• Vendor
• Module Type (the combination of Product Type and Product Code for a
particular Vendor)
• Major Revision
Mismatch does not agree with what is specified on the General Tab
IMPORTANT
The following modules return an error if a reset is
attempted:1756-L1 ControlLogix5550 Programmable
Controller; 1336T AC Vector Drive; 1395 Digital DC
Drive.
