Publication 1784-UM003A-EN-P – June 2003
342 Motion Object Attributes
Servo Fault Configuration
Servo Fault Actions Each axis can be configured to respond to each of the five types of servo faults
in any one of four different ways. This flexibility is important because motion
control applications differ widely in their fault action requirements.
Shutdown
If a fault action is set to Disable Drive, then when the associated fault occurs,
axis servo action is immediately disabled, the servo amplifier output is zeroed,
and the appropriate drive enable output is deactivated. Furthermore, this fault
action opens the OK contact associated with the servo module which can be
used to open the E-Stop string to the drive power supply. Shutdown is the
most severe action to a fault and it is usually reserved for faults which could
endanger the machine or the operator if power is not removed as quickly and
completely as possible.
GSV/SSV Access Attribute Name Data Type Values
SSV/GSV Soft Overtravel Fault Action SINT 0 = shutdown
1 = disabled drive
2 = stop command
3 = status only
SSV/GSV Hard Overtravel Fault Action SINT 0 = shutdown
1 = disabled drive
2 = stop command
3 = status only
SSV/GSV Position Error Fault Action SINT 0 = shutdown
1 = disabled drive
2 = stop command
3 = status only
SSV/GSV Feedback Fault Action SINT 0 = shutdown
1 = disabled drive
2 = stop command
3 = status only
SSV/GSV Feedback Noise Fault Action SINT 0 = shutdown
1 = disabled drive
2 = stop command
3 = status only
SSV/GSV Drive Fault Action SINT 0 = shutdown
1 = disabled drive
2 = stop command
3 = status only
