Publication 1784-UM003A-EN-P – June 2003
Specifications and Performance 419
Glass Fiber Optic Specifications
Transmission Range
Core Diameter
Cladding Diameter
Cable Attenuation
Operating Temperature
Connector
Bend Radius
1-200 meters
200
μm ± 4μm
230
μm +0/−10μm
6.0 dB/km @ 820nm
-20 to 85
° C
F-SMA standard screw-type connector
2.5 cm
SERCOS
SERCOS Class
Data Rate
Operating cycle
1784-PM16SE @ 4 Mbaud
1784-PM16SE @ 8 Mbaud
Class B (Position or Velocity)
4 Mbits or 8 Mbits per second
0.5 ms for up to 2 axes
1 ms for up to 4 axes
2 ms for up to 8 axes
No support for 9 to16 axes
0.5 ms for up to 4 axes
1 ms for up to 8 axes
2 ms for up to 16 axes
Agency certification
(when product or packaging is
marked)
UL Recognized Component Industrial Control
Equipment for Class I, Division 2, Groups A,
B, C, D Hazardous Locations, certified for US
and Canada
EN50081-2; Industrial Emissions
EN61000-6-2; Industrial Immunity
