78 Configuring the1784-PM16SE Card
Module Identity
This field does not take into account the Electronic Keying or Minor Revision
selections for the card that were specified on the General Tab.
Refresh
Click on this button to refresh the tab with new data from the card.
Reset Module
Click on this button to return a card to its power-up state by emulating the
cycling of power.
Resetting a card causes all connections to or through the card to be closed, and
this may result in loss of control.
Displays:
If the card in the physical slot:
Match
agrees with what is specified on the General Tab. In order for the Match
condition to exist, all of the following must agree:
• Vendor
• Module Type (the combination of Product Type and Product Code for a
particular Vendor)
• Major Revision
Mismatch
does not agree with what is specified on the General Tab
