Digital StoreFront 5.2 Administration Reference
302
•
Media Type—Select a type for the media.
• Media Tab Count—Specify the number of tabs on the media. This will cause the tab definition
panel to open:
•
Specify the dimensions of the tabs in the Tab Measure fields:
o
Tab Measure 1: specifies the height of the tab (the length from the edge of the page to
the leading edge of the tab).
o
Tab Measure 2: specifies the length of the leading edge of the tab.
o
Tab Measure 3: specifies the length of the tab's outdent (the distance between its two
outdent endpoints).
o
Tab Measure 4: specifies the distance from the top edge of the page to the first
outdent of the tab.
o
Tab Measure 5: specifies the distance from the bottom tab (last) tab on the page to the
bottom edge of the page.
Quick Reference: How to Create Tab Media Products
Media:
1. On the View or Edit Catalog tab of the Media page, define the media
characteristics as appropriate and select Tab Stock from the Media
Type pull-down list.
2. Specify the number of tabs in the Tab Count field. This will cause the
tab definition panel to open.
3. Specify the dimensions of the tabs in the appropriate Tab Measure
fields.
Ticket Template:
4. On the Ticket Template page, create or open a ticket template that
you want to have a tab media option.
5. In Section 2, click Add Print Service(s).
6. Locate and select “Tabs.”
7. Click Add.
8. On the Tabs dialog, check the box(es) to enable the tab media.
