Yaskawa MP2200 Machine Controller - Manual (Page 99)

3.2 SVA-01 Module Setup
3-27
( 1 ) Module Configuration Definitions
The following diagram shows a sample Module configuration definition achieved by installing a
218IF-01 Module and SVA-01 Module in the MP2200/MP2300 Option Slot, and executing self-
configuration.
■ MP2300 Example
EXAMPLE
