Chapter 12 Color correction 393
2 Choose the scope to display from the top section of the Settings pop-up menu.
Choose the scope you
want to use from the
Settings pop-up menu.
Viewer Options
pop-up menu
3 After you choose a scope, choose the display options from the bottom section of the Settings
pop-up menu.
Note: You may find it convenient to display scopes below the video image in the Event Viewer.
To do so, choose Vertical Layout from the Settings pop-up menu in the Event Viewer. For more
information, see
Play back and skim media in the Event Viewer on page 82.
Waveform Monitor display options
The Waveform Monitor shows the relative levels of luma and chroma in the clip currently being
examined. These values are displayed from left to right, mirroring the relative distribution of luma
and chroma levels from left to right in the image. Spikes and dips in the displayed waveforms
correspond to light and dark areas in your picture. The waveforms are also tinted to match the
color of items in the video.
