3
PM Designer Operation Manual
3-36
CHAPTER 3 CREATING PANEL APPLICATIONS
The number in this word will be used as the current recipe number of recipe block #0 when bit 5 of Command Flag
Register changes from Off to On.
■ Type H (Binary) Status Words
You can have the following status words for the application.
Status Word Description
Screen Status Word
Whenever the panel switches the main screen, it sets this word to the number of
the current main screen.
Command Flag Ack. Word Contains the acknowledge bits for the command flags of Command Flag Register.
Current Recipe Number Word Stores the current recipe number of recipe block #0.
3.6.1.3. Type H (BCD)
The command words and status words you can have for the application are the same as the H (Binary) type. However, the
values in the following words must be in BCD format: Screen Number Register, Recipe Number Register, Screen Status
Word, and Current Recipe Number Word.
