9
PM Designer Operation Manual
9-12
CHAPTER 9 ANIMATED OBJECTS
Property Description
Anchor Point Select one of the following our corners of the dynamic rectangle that will not
move when its size changes: Upper Left, Upper Right, Lower Left, and Lower
Right. This item is available when the Size is controllable but the Position is not
controllable.
Solid Check this option if you want the dynamic rectangle to be filled with the
selected pattern.
Pattern Select a pattern for filling the dynamic rectangle.
FG Color Select a color for painting the black part of the pattern. This item is available
when the Pattern is not solid white.
Solid
BG Color Select a color for painting the white part of the pattern.
Border Check this option if you want the dynamic rectangle to have a border.
Rectangle
Border
Border
Color The border color.
