PM Designer Operation Manual
9-1
CHAPTER 9 ANIMATED OBJECTS
9.1. Pipelines
9.1.1. Basic Operations
You can create a pipeline easily and efficiently. At runtime you can control a pipeline to change color, blink, and/or show the
flow effect dynamically.
9.1.2. Operation Options
The following operation option can be added to a pipeline. Select and set up the option in the Pipeline property sheet.
Options Description
Visibility
Control You can show and hide a pipeline by a specified bit or the current user level. Select and set up this
option in the Visibility page.
9.1.3. Settings
You can complete all the settings of a pipeline in the Pipeline property sheet. This sheet contains the following three pages.
■ General
Described in Section 9.1.4.
■ Pipe
Described in Section 9.1.5.
■ Visibility
Described in Section 4.3.4.
