PM Designer Operation Manual
1-27
CHAPTER 1 INTRODUCTION
■
Text Database Node ( )
You can do the following with the Text Database node:
1) Double-click it to open the Text Database dialog box.
2) Right-click it to get a popup menu with the following menu item:
Menu Item Description
Open Open the Text Database window.
■
Global Tags Node ( )
You can do the following with the Global Tags node:
1) Double-click it to open the Global Tags window.
2) Right-click it to get a popup menu with the following menu item:
Menu Item Description
Open Open the Global Tags window.
■
Global Macros Node ( )
The Global Macros node can have many Global Macro sub-nodes. Each Global Macro node is associated with a global
macro of the project. You can do the following with the Global Macros node:
1) Double-click it to expand or collapse the list of its sub-nodes.
2) Right-click it to get a popup menu with the following menu items.
Menu Item Description
Add Macro... Create a new global macro.
Import
Macro... Import a global macro from an MCR file.
■
Global Macro Node ( )
Each Global Macro node is associated with a global macro of the project. You can do the following with the Global Macro
node:
1) Double-click it to open the editing window of the associated macro.
2) Right-click it to get a popup menu with the following menu items.
Menu Item Description
Open Open the editing window of the associated macro.
Close Close the editing window of the associated macro.
Rename Rename the associated macro.
Delete Delete the associated macro.
Export Macro... Export the associated macro to an MCR file.
