PM Designer Operation Manual
8-23
Property Description
Dynamic
Range Check this option so the minimum and the maximum of the pen for each data set will be
specified at runtime. When this option is selected, the minimum and maximum of the marks
for the X axis and Y axis can be specified at runtime too. The data that specifies the above
two ranges should be set and arranged correctly in a memory block called the dynamic
range parameter block. You need to specify the dynamic range parameter block in the
Dynamic Range Parameter Block field. Dynamic
Range
Dynamic
Range
Parameter
Block Specifies the variable that stores the dynamic range parameter block for the line chart when
the Dynamic Range is selected. Click to enter an address for this field. Click to
select a tag for this field.
The following table shows the data arrangement of the parameter block when the data type
is 16-bit.
Word Description
0,1 The minimum of the mark for the X axis; 32-bit integer number
2,3 The maximum of the mark for the X axis; 32-bit integer number
4,5 The minimum of the mark for the Y axis; 32-bit integer number
6,7 The maximum of the mark for the Y axis; 32-bit integer number
8 The minimum for pen #1; 16-bit integer number or 16-bit unsigned integer number
9 The maximum for pen #1; (Same as above)
10 The minimum for pen #2; (Same as above)
11 The maximum for pen #2; (Same as above)
… …
22 The minimum for pen #8; (Same as above)
23 The maximum for pen #8; (Same as above)
The following table shows the data arrangement of the parameter block when the data type
is 32-bit.
Word Description
0,1 The minimum of the mark for the X axis; 32-bit integer number
2,3 The maximum of the mark for the X axis; 32-bit integer number
4,5 The minimum of the mark for the Y axis; 32-bit integer number
6,7 The maximum of the mark for the Y axis; 32-bit integer number
8,9 The minimum for pen #1; 32-bit integer number, 32-bit unsigned integer number, or
32-bit floating point number
10,11 The maximum for pen #1; (Same as above)
12,13 The minimum for pen #2; (Same as above)
14,15 The maximum for pen #2; (Same as above)
… …
36,37 The minimum for pen #8; (Same as above)
38,39 The maximum for pen #8; (Same as above)
CHAPTER 8 GRAPHS AND CHARTS
