CHAPTER 12 DATA COLLECTION AND HISTORIC DISPLAYS
The following table describes each property in the Pen page.
Property Description
Min. The minimum of the associated data set. This property is available when the Dynamic
Range option is not selected.
Max. The maximum of the associated data set. This property is available when the Dynamic
Range option is not selected.
Mark Size Select a size for the data point mark. The selection is valid when the Show Mark option in
the General page is selected.
Line Style Select a style for the connecting lines. The selection is valid when the Show Line option in
the General page is selected.
Color Select a color for the connecting lines.
Historic
Data Pen
Show Value Select one of the following methods for displaying the selected data point value.
Show Value Description
(None) Does not display the data point value.
Original Displays the data point value without modification.
Scaled Displays the corresponding Y axis value of the data point.
The selection is valid when the Show Cursor option in the General page is selected.
Min. The minimum of the associated data set. This property is available when the Dynamic
Range option is not selected.
Max. The maximum of the associated data set. This property is available when the Dynamic
Range option is not selected.
Mark Size Select a size for the data point mark. The selection is valid when the Show Mark option in
the General page is selected.
Line Style Select a style for the connecting lines. The selection is valid when the Show Line option in
the General page is selected.
Color Select a color for the connecting lines.
Reference
Data Pen
Show Value Select one of the following methods for displaying the selected data point value.
Show Value Description
(None) Does not display the data point value.
Original Displays the data point value without modification.
Scaled Displays the corresponding Y axis value of the data point.
The selection is valid when the Show Cursor option in the General page is selected.
Line segment color
selectable individually Check this option to set the line segment color individually in the following list window.
The list window has three columns. The first column is line segment number. The second
column is color setting for the data line. The third column is the color setting for reference
line.
