4
PM Designer Operation Manual
4-12
CHAPTER 4 DESIGNING SCREENS
The following table describes each property in the Circle dialog box.
Property Description
Color Controlled
By Bit Check this option if the color of the circle will be controlled by the specified
bit.
Control Bit Specifies the bit that controls the color.
Click to enter the bit address. Click to enter the bit tag.
Color
Control
State Select the state that you want to view or define the colors for.
Outlined Check this option if you want the circle to be outlined. Outline
Color Specifies the outline color for the selected state.
Solid Check this option if you want the circle to be solid. A solid circle is filled with
the specified pattern and colors.
Pattern Specifies the fill pattern for the selected state.
FG Color Specifies the color for the selected state that will be used for painting the
black part of the fill pattern.
Solid
BG Color Specifies the color for the selected state that will be used for painting the
white part of the fill pattern.
X The X coordinate of the center of the circle.
Y The Y coordinate of the center of the circle.
Profile
Radius The radius of the circle.
Visibility
Controlled By Bit Check this option if the circle will be shown or hidden by the specified bit.
Control Bit Specifies the bit that shows or hides the circle.
Click to enter the bit address. Click to enter the bit tag.
Visibility
Control
Visible State Specifies the state (On or Off) that makes the circle visible.
7. You can click the following icons in the Draw toolbar to modify the properties of the circle.
Click Icon To
Select a color for the outline.
Select a color for painting the white part of the fill pattern.
Select a pattern for the fill pattern.
Select a color for painting the black part of the fill pattern.
