PM Designer Operation Manual
5-35
CHAPTER 5 BUTTONS AND SWITCHES
5.9. Customizing Keypad Using Keypad Buttons
You can use keypad buttons to create your own keypads.
Keypad Button: Used for creating a touch cell as a panel
key (i.e., Enter). Panel keys represent all of the function keys, numeric keys, and arrow keys, as well as the
escape key, the clear key, the enter key, the +/- key, and the decimal point key.
觸控屏鍵盤按鍵 Keypad Button : 用來將觸控按鈕設為鍵盤鍵（例如〔輸入〕鍵）。觸控屏按鍵可代表所有的功能鍵、
數字鍵、方向鍵、還有求助鍵(Help)、清除鍵、輸入鍵、+/-鍵、小數點等。
5.9.1. Basic Operations
A keypad button inputs a character to the keypad buffer or issues a command to the keypad buffer when it is pressed. You
can create your own keypads as the custom keypads for your application. For details, see ?, ?. The following is a custom
keypad.
5.9.2. Operation Options
The following operation options can be added to a keypad button to make it more useful. You need to select and set these
options in the Keypad Button dialog box.
Options Description
Macro
所有鍵盤按鈕也可以提供一巨集程式
Visibility Control The keypad button can be shown or hidden either by a specified bit or by the current user
level. Select and set this option in the Visibility page.
5.9.3. Settings
You can complete all the settings of a keypad button in the Keypad Button dialog box. This dialog box contains the
following four pages. Some of the pages appear only when they are needed.
■ General
Described in Section 5.9.4.
