PM Designer Operation Manual
10-13
CHAPTER 10 RECIPES AND RECIPE OBJECTS
The following table describes each property in the General page.
Property Description
ID The object’s identifier. It is generated when the object is created and is
unchangeable. The identifier is unique within the screen where the object is on.
The format of the ID’s for the recipe selectors is RSnnnn.
Note You can type a note for the object.
Shape settings For details about the following properties, Section 4.3.1.4 Setting up the Shape of
an Object. , Border Color, BG Color
Type Select one of the following types for the recipe selector:
Type Description
List The list box is displayed at all times.
Drop-down List The list box is not displayed unless the user clicks the
down arrow icon next to the static-text control.
Recipe Block Select the recipe block whose recipe is to be selected by the Recipe Selector
object.
Recipe Name Select a data item from the list as the recipe name. You can select any data items
with ASCII String data type as the name of the recipe from the drop down list.
Sort by Recipe Name Check this option to automatically sort all recipe names added to the list box.
Font The font of the displayed string.
Text Color The color of the displayed string.
