3
PM Designer Operation Manual
3-48
CHAPTER 3 CREATING PANEL APPLICATIONS
Property Description
Time/date Data Type
Data Type Description
8 BCD bytes The following shows the data structure.
Byte No. Content
0 Minute; 0~59
1 Hour; 0~23
2 Day; 1~31
3 Month; 1~12
4 Year; 00~99
5 Day-of-week; 0(Sunday)~6(Saturday)
6 Second; 0~59
7 0
Note: All the values are in BCD format.
7 BCD words The following shows the data structure.
Word No. Content
0 Second; 0~59
1 Minute; 0~59
2 Hour; 0~23
3 Day; 1~31
4 Month; 1~12
5 Year; 00~99
6 Day-of-week; 0(Sunday)~6(Saturday)
Note: All the values are in BCD format.
7 binary words The following shows the data structure.
Word No. Content
0 Second; 0~59
1 Minute; 0~59
2 Hour; 0~23
3 Day; 1~31
4 Month; 1~12
5 Year; 00~99
6 Day-of-week; 0(Sunday)~6(Saturday)
Write Address Specifies the variable that will receive the output time and date information.
Timed When this item is selected, the panel writes time and date information to the
specified variable periodically at a rate specified in the Interval field. You can
specify an interval between 1 and 255 minutes.
Write
Write
Operation
Triggered When this item is selected, the panel writes time and date information to the
specified variable whenever the specified trigger bit changes from Off to On.
Continued
