PM Designer Operation Manual
5-6
CHAPTER 5 BUTTONS AND SWITCHES
5.2. Toggling Bit State Using Toggle Switches
You can touch a toggle switch to toggle the state of the specified bit.
The difference between a toggle switch and a bit button performing Invert operation is described below:
1) A toggle switch performs the toggle operation by writing the inverse state of the monitored bit to the destination bit.
2) A bit button performs the Invert operation by inverting the destination bit directly regardless of the monitored bit.
5.2.1. Settings
You can complete all the settings of a toggle switch in the Toggle Switch property sheet. This sheet contains the following
seven pages. Some of the pages appear only when they are needed.
■ General
Described in Section 5.2.2 .
■ Label
Described in Section 4.3.1.5.
■ Advanced
Described in Section 4.3.3.
■ Visibility
Described in Section 4.3.4.
■ External Label
Described in Section 4.3.1.8.
■ On Macro
Described in Section 14.2.6.
■ OFF Macro
Described in Section 14.2.6.
