10
PM Designer Operation Manual
10-6
CHAPTER 10 RECIPES AND RECIPE OBJECTS
10.5. Setting up Recipe Blocks
You can set up a recipe block with the Recipe Block dialog box. There are two ways to open the dialog box of a recipe
block:
1) In the PM Designer's Project Manager window, right-click the node of the desired Recipe Block and select Properties.
2) In the PM Designer's menu bar, click Panel to bring up the Panel sub-menu. Click Recipes in the Panel sub-menu to
bring up the Recipe Block pop-up menu. Select Properties in the pop-up menu to bring up the recipe block list of the
current panel application. Select the recipe block in the list.
The Recipe Block dialog box contains the following two pages:
■ General
Described in Section 10.5.1 .
■ Data Item
Described in Section 10.5.2.
10.5.1. General Settings
Use the General page to define the general settings for a recipe block. The following is an example of the General page.
