PM Designer Operation Manual
2-17
CHAPTER 2 CREATING PROJECTS
2.3.3. Creating Tags by Tags Editor
You can use tags editor to create and manage tags. The tags editor is split into two panes: Tag Group Explorer on the left
and Tag List Window on the right. Each pane scrolls separately, both horizontally and vertically. You can position the
mouse over the vertical splitter bar and drag the bar to resize the panes.
The following is an example of the tags editor.
Tag Group Explorer Tag List Window
Tag Groups
Vertical Splitter Bar
List all the Tags for the
active tag group named
MONITOR
List all the Tags for the link
